Sachet Sorting and Carton Box Packing Machine

●We supported customizing the automatic carton box packing line. Directly connect the production system, sachet conveying-counting-laminating-bag packing-carton box packing.

●It includes three kinds, the spray glue, the plug-in box, and the bottom buckle. The automatic carton box packing machine is suitable for food, medical, daily products, hardware products, such as cake, biscuits, soap, gloves, face masks, etc.



●The parts are fully stainless steel.





  • UPZH-80

Availability:

1

Sachet Sorting and Carton Box Packing Machine

123

Overview

Pillow Packing and Boxing Machine

Made from high quality stainless steel, this machine is built to last and is capable of packaging 50-80 boxes per minute! Our Packing Machine is also compatible with the spray glue, plug in, and bottom buckle packing boxes and is easy to use and customize. This machine is designed to package several smaller products together, or package one larger product individually.


● Made from high quality stainless steel and equipped with intelligent detecting systems.

● Compatible with a variety of packing materials and products.

● Able to accurately count, wrap, label, and package almost any small to medium sized product at a rate of 50-80 boxes per minute.

● Easy to use and customize, and comes with excellent post-sale customer service.

● Quality Assurance Certifications and patents are available!


Technical Feactures

▶All outer casings of the machine are made of stainless steel.

▶PLC and Touch-screen Control, equipped with intelligent detecting systems.

▶No Product detected, then no carton will open.

▶No Carton detected, then no leaflet inserted.

▶If no Product & Leaflet loaded into the carton, it automatically rejects.

▶Easy operation and easy adjustments for changing carton sizes.

▶This machine operates on Mechanical Type System, thus resulting in durability, reliability, and perfect packaging appearance.

▶It can be used on Hot-Melt Glue Sealing Carton (OPTIONAL).

▶Various types of automatic feeding units/systems (OPTIONAL) are available such as blisters, bottles, tubes, etc.


Parameters


Product Name

Sachet Sorting and Carton Box Packing Machine

Carton Size Range

Max. L260×W120×H90mm

Min. L80×W80×H30mm

Packing Capacity

50-80 boxes/min

Noise

<80 dB

Net Weight

1500kg

Power Supply

220V 50Hz

Total Power

4K

Outer Size

5000*1500*1900mm

Application

It is suitable for packaging various medicines, auto parts, food, cosmetics, tissues, and small utensils in various industries.

Application

The automatic carton box packing machine is suitable for aluminum-plastic/aluminum-plastic-aluminum/aluminum-aluminum medicinal plates, pillow packaging bags, oral liquid trays, suppositories, plasters, chicken essence, mosquito coil, facial masks, eye patches, etc. in the pharmaceutical, food, health care, cosmetics, and other industries automatic cartoning box and sealing.

4

Detailed images

567


ABOUT UPPER



Foshan Upper Machinery Equipment Co., Ltd. is an innovative automated packaging equipment manufacturer integrating R&D, design, manufacturing, sales and after-sales. Since its establishment more than ten years ago, the company has attracted a group of more than 80 professionals who are persistently pursuing the mechanical industry. The number of talents who have grown up with the company has reached 12, and they have designed and manufactured automatic packaging equipment with leading technology in China and oversea.


The company specializes in manufacturing: automatic product flow packaging line, pillow packaging machine, food packaging machine, daily chemical products packaging machine, hardware accessories packaging machine, pouch dispenser, secondary packaging machine, automatic carton packing filling machine, bag sorting machine, customized counting collection machine, customized processing line packaging equipment.


Foshan Upper Machinery Equipment Co., Ltd. has professional technical personnel, engineers, sales and after-sales service personnel, forming a high-quality, young and innovative team. Always adhere to the tenet of "scientific and technological innovation, quality first, steady development, sincerity and trustworthiness", and provide customers with high-quality products and services.

56


Workshop


7

Production Process

8

9

Pre-sale service

1. Training customers' engineers to learn how to use packing machines

2. Testing packing machines, with product sample and our film materials.

3. Machine testing videos will be sent to customers.

After-sale service

1. Providing manual book

2. Videos of installation, adjusting, setting, and maintenance are available.

3. Telecommunucations and face to face online communications are available.

4. Engineer oversea services are avallable. The round-tip air tickets, hotel, meal, and visa cost of our engineers shall bebome by the Buyer.

5. Machine qualty guarantee perlod is 1 year. During guarantee perod, Ir there is no man-made damage, we will replacenew ones for you. The guarantee period will start from the date of B/L.

售后


One of our Australia customer, asked for the engineer for the service for the automatic biscuit feedingpacking machine.4 set pillow  packing machine + one set feeding machine. Two of our engineers have a good technical service and training service there

5253
